MSI X299 GAMING M7 ACK, Socket 2066, DDR4 Anakart
(Stokta Yok)
Ürün Detayı
| MSI X299 GAMING M7 ACK |
| Socket Türü: Socket 2066 |
| Vga Türü: PCIExp |
| Ram Türü: DDR4 |
| Çipset: Intel X299 |
| Main Memory |
| • 8 x DDR4 memory slots, support up to 128GB* |
| • Quad channel memory architecture with the CPU that supports up to 4-channels DDR4** |
| - X-series processor support DDR4 4133+(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2667/2400/2133 MHz* |
| • Dual channel memory architecture with the CPU that supports up to 2-channels DDR4** |
| - X-series processor support DDR4 4500+(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2667/2400/2133 MHz* |
| • Supports Intel® Extreme Memory Profile (XMP) |
| Slots |
| • 4 x PCIe 3.0 x16 slots |
| - Support x16/ x4/ x16/ x8 mode with the 44-lane CPU. |
| - Support x16/ x4/ x8/ x0,x8/ x4/ x8/ x8 modes with the 28-lane CPU. |
| - Support x8/ x0/ x8/ x0, x8/ x4/ x4/ x0 modes with the 16-lane CPU. |
| • 2 x PCIe 3.0 x1 slots |
| Multi GPU: |
| • Supports 3-Way AMD® CrossFire™ Technology |
| • Supports 3-Way NVIDIA® SLI™ Technology |
| Storage |
| • Intel® X299 Chipset |
| • 8 x SATA 6Gb/s ports* |
| • 2 x M.2 slots (Key M)* |
| - Supports up to PCIe 3.0 x4 and SATA 6Gb/s |
| - M2_1 slot supports 2242/ 2260 /2280 storage devices |
| - M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices |
| - Intel® Optane™ Memory Ready** |
| • 1 x U.2 port * |
| - Supports PCIe 3.0 x4 NVMe storage |
| • Supports Intel® Smart Response Technology*** |
| Raid: |
| • Intel® X299 Chipset |
| • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| • Supports RAID 0 and RAID 1 for M.2 storage devices* |
| USB |
| • ASMedia® ASM3142 Chipset |
| - 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel |
| - 2 x USB 3.1 Gen2 (Super Speed USB 10Gbps) Type-C ports(1 port on the back panel, 1 port available through the internal USB connector) |
| • ASMedia® ASM1074 Chipset |
| - 3 x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on theback panel |
| • Intel® X299 Chipsett |
| - 5 x USB 3.1 Gen1 (SuperSpeed USB) ports (1 port on the back panel, 4 ports available through the internal USB connectors) |
| - 7 x USB 2.0 (High-speed USB) ports (3 ports on the back panel, 4 ports available through the internal USB connectors) |
| Wirsless LAN & Bluetooth |
| • Killer™ Wireless-AC 1535 module |
| - The Wireless module is pre-installed in the M2_3(Key-E) slot. |
| - Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz,5GHz) up to 867 Mbps speed. |
| - Supports Bluetooth® 4.1 |
| Audio |
| • Dual Realtek® ALC1220 Codec |
| - 7.1-Channel High Definition Audio |
| - Supports S/PDIF output |
| LAN |
| 1 x Killer™ E2500 Gigabit LAN controller |
| Back Panel I/O Ports |
| - 1 x Clear CMOS button |
| - 1 x BIOS FLASHBACK+ button |
| - 1 x PS/2 keyboard/ mouse combo port |
| - 3 x USB 2.0 Type-A ports |
| - 2 x Wi-Fi Antenna connectors (optional) |
| - 4 x USB 3.1 Gen1 Type-A ports |
| - 1 x LAN (RJ45) port |
| - 1 x USB 3.1 Gen2 Type-A port |
| - 1 x USB 3.1 Gen2 Type-C port |
| - 1 x Optical S/PDIF OUT connector |
| - 5 x OFC audio jacks |
| Dimension |
| • 12 in. x 9.6 in. (30.5 cm x 24.4 cm) |
| • ATX Form Factor |
| Mounting |
| • 9 mounting holes |
| Garanti: 36 Ay |
