ASUS TUF X299 MARK 2, Socket 2066, DDR4 Anakart

ASUS TUF X299 MARK 2





Stok Durumu : Stokta Yok (Stokta Yok)


Ürün Detayı
Socket Türü: Socket 2066
Vga Türü: PCIExp
Ram Türü: DDR4
Çipset: Intel X299
Main Memory
8 x DIMM, Max. 128GB, DDR4 4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz ECC olmayan, Arabelleksiz Bellek
Intel® Core? X-series Processors (6-core above)
Intel® Core? X-series Processors (4-core)
4 x DIMM, Max. 64GB, DDR4 4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz ECC olmayan, Arabelleksiz Memory
* Hyper DIMM desteği her işlemcinin fiziksel özelliklerine bağlıdır.
* QVL Listesi için www.asus.com.trı ziyaret ediniz.
Genişletme Slotları:
44-Lane CPU-
3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)
1 x PCIe 3.0 x4 (max at x2 mode) *1
2 x PCIe 3.0/2.0 x1
28-Lane CPU-
2 x PCIe 3.0/2.0 x16 (x16, x16/x8)
1 x PCIe 3.0 x4 (max at x2 mode) *1
2 x PCIe 3.0/2.0 x1
16-Lane CPU-
2 x PCIe 3.0/2.0 x16 (x16 veya dual x8)
1 x PCIe 3.0 x4 (max at x2 mode) *1
2 x PCIe 3.0/2.0 x1
Multi GPU:
NVIDIA® Quad-GPU SLI? Teknolojisini Destekler
NVIDIA® 3-Way SLI? Teknolojisini Destekler
NVIDIA® 2-Way SLI? Teknolojisini destekler
AMD Quad-GPU CrossFireX? Teknolojisini Destekler
AMD 3-Way CrossFireX? Teknolojisini Destekler
Depolama
Intel® X299 Chipset :
1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
6 x SATA 6Gb/s port(s)
Raid Desteği 0, 1, 5, 10
Supports Intel® Smart Response Technology
Intel® Rapid Storage Technology 15 support
Support Intel® Rapid Storage Technology enterprise 5.1 for X-Series(6-core and above) CPU RAID
Intel® Optane? Memory Ready
SES:
Realtek® ALC S1220A 8-Kanal High Definition Audio CODEC
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Destekler : Jack-detection, Multi-streaming, Front Panel Jack-retasking
LAN
Intel® I219V, 1 x Gigabit LAN Kontrolcüsü(leri), featuring Turbo LAN
ASUS Turbo LAN Utility
Back Panel I/O Ports
1 x PS/2 klavye/fare combo port(s)
1 x LAN (RJ45) port(s)
2 x USB 3.1 Gen 2 Type-A
4 x USB 3.1 Gen 1
1 x Optik S/PDIF çıkışı
4 x USB 2.0
5 x Audio jack(s)
Anakart Boyutları
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) D
Garanti: 36 Ay
