MSI CREATOR X299, Socket 2066, DDR4 Anakart
(Stokta Yok)
Ürün Detayı
| Model: MSI CREATOR X299 |
| Socket Türü: Socket 2066 |
| Vga Türü: PCIExp |
| Ram Türü: DDR4 |
| Çipset: Intel X299 |
| Main Memory |
| 8 x DDR4 memory slots, support up to 256GB1 |
| Support DDR4 4266+(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2933/ 2666/ 2400/ 2133 |
| Quad channel memory architecture |
| Supports Intel® Extreme Memory Profile (XMP) |
| Slots |
| 4 x PCIe 3.0 x16 slots |
| Support x8/ x8/ x16/ x8 and x16/ x0/ x16/ x8 modes with the 48-lane CPU. |
| Support x8/ x8/ x16/ x8 and x16/ x0/ x16/ x8 modes with the 44-lane CPU.1 |
| Support x8/ x8/ x8/ x0 and x16/ x0/ x8/ x0 modes with the 28-lane CPU.2 |
| The PCI_E4 slot will run 3.0 x4 speed with 44-lane CPU when installing M.2 PCIe device into M2_3 slot. |
| The PCI_E4 slot is unavailable with 28-lane CPU. |
| Multi GPU: |
| Supports 4-Way NVIDIA® SLI® Technology1 |
| Supports 4-Way AMD® CrossFire™ Technology1 |
| Depends on the installed CPU. |
| Storage |
| Intel X299 Chipset |
| 8 x SATA 6Gb/s ports |
| 1 x M.2 slots (Key M)1 |
| Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices |
| Intel® Rapid Start Technology |
| Intel® Optane™ Memory Ready |
| 1 x U.2 port, supports PCIe 3.0 x4 NVMe storage |
| Supports Intel® Smart Response Technology |
| Intel CPU |
| 2 x M.2 slots (M2_2 & M2_3, Key M)1 |
| Support up to PCIe 3.0 x4, 2242/ 2260/ 2280/ 22110 storage devices1 |
| M2_3 slot is unavailable with 28-lane CPU. |
| Raid: |
| Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Supports RAID 0, RAID 1 for M.2 PCIe storage devices |
| Wirsless LAN & Bluetooth |
| Intel Wi-Fi 6 AX200 |
| Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps |
| Supports Bluetooth® 5.1 |
| The Wireless module is pre-install in the M2_4 (Key-E)slot |
| SES |
| Realtek ALC1220 Codecs |
| 7.1-Channel High Definition Audio |
| Supports S/PDIF output |
| LAN |
| 1 x Intel® I219-V Gigabit LAN controller |
| 1 x Aquantia® AQC107 10-Gigabit LAN controller |
| Back Panel I/O Ports |
| Clear CMOS Button |
| Keyboard / Mouse |
| Gigabit LAN |
| 10G LAN |
| Audio Connectors |
| Flash BIOS Button |
| Wireless / Bluetooth |
| USB 2.0 |
| USB 3.2 Gen1 Type-A |
| USB 3.2 Gen2x2 20G Type-C |
| USB 3.2 Gen1 Type-A |
| Optical S/PDIF out |
| Dimension |
| 12 in. x 10.7 in. (30.5 cm x 27.2 cm) |
| E-ATX Form Factor |
| Mounting |
| • 9 mounting holes |
| Garanti: 36 Ay |
