model no
CA-3R8-65M1WE-00
|
SERİ
|
H Series
|
MODEL
|
H330 TG
|
KASA TİPİ
|
Middle tower
|
BOYUTLAR (Y X G X D)
|
419 x 210 x 480 mm
|
(16.5 x 8.27 x 18.9 inch)
|
|
NET AĞIRLIK
|
6.12 kg / 13.49 lb
|
YAN PANEL
|
4mm Tempered Glass x1(Left)
|
RENK
|
Exterior & Interior : Black
|
MALZEME
|
SPCC
|
SOĞUTMA SİSTEMİ
|
3x120mm ARGB Fan
|
SÜRÜCÜ YUVALARI
|
-ULAŞILABİLİR
|
-GİZLİ
|
|
2 x 3.5" or 2.5” (HDD Rack); 2 x 2.5” (HDD Bracket)
|
GENİŞLEME YUVALARI
|
7
|
ANAKARTLAR
|
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
|
I/O PORT
|
1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio,
|
GÜÇ KAYNAĞI
|
Standard PS2 PSU (optional)
|
FAN DESTEĞİ
|
Front:
|
3 x 120mm or 2 x 120mm or 1 x 120mm
|
2 x 140mm or 1 x 140mm
|
2 x 200mm or 1 x 200mm
|
Top:
|
2 x 120mm or 1 x 120mm
|
2 x 140mm or 1 x 140mm
|
Rear:
|
1 x 120mm,
|
RADYATÖR DESTEĞİ
|
Front: 1 x 360mm or 1 x 240mm or 1 x 120mm
|
1x 280mm or 1 x 140mm
|
Top: 1 x 240mm or 1 x 120mm
|
Rear: 1 x 120mm
|
BOŞLUK
|
CPU cooler height limitation: 150mm
|
PSU length limitation: 160mm(With HDD Rack)
|
200mm(Without HDD Rack)
|
VGA length limitation: 300mm
|
RAM height limitation: 60mm(With radiator series)
|
|
Garanti Süresi (Ay) : 24
|
